SatLink VSAT User Guide
Publication no. 101557
Copyright © 2009 – STM Group, Inc.
Page 82 (160)
Ethernet (LAN) : 00:60:c0:2f:ba:83
Satellite (DVB) : 00:60:c0:2f:ba:83
When the card has been detected by the VSAT, the DVB-S2 is configured the same was as DVB-S.
described in section 9.2.3.
Example:
# dvb rx fwdlink 0 0 25000000 12380000 dvbs2 2
# save config
# dvb rx show
Satellite (DVB) RX Configuration
--------------------------------
Auto start : Disabled
Idx Pri Freq[GHz] SymbRate[Msps] Mode PopId
* 0 0 12.380000 25.000000 DVB-S2 2
DVB Receiver Status (SatLink 100)
--------------------------------
Rx State : Waiting for NIT (transponder one)
Frequency : 12.380887 GHz
Symbol Rate : 24.999998 Msps
Modulation : 8PSK
FEC Code rate : 2/3
Pilot : On
Frame length : Long frame
Roll off : 0.35
SNR : 15.2 dB
For SatLink 1910 and 1000 having revision 2.0 or newer there is no need for the SatLink 100 plug-in card
as they have built in DVB-S2 receives capabilities as default. Both models are configured the same way
as the example shows above.
If there is any doubt on whether a SatLink VSAT is capable of receiving DVB-S2, issue the CLI
command
device show -dvbs2.
Example:
# device show -dvbs2
DVB-S2 capability
This device supports DVB-S2.
