DocID030906 Rev 2 15/78
UM2271 Hardware layout and configuration
77
10.2 32L4R9IDISCOVERY mechanical drawing
Figure 6. 32L4R9IDISCOVERY mechanical drawing (top view, in mm)
Legend:
= Indicates the mounting hole between the 32L4R9IDISCOVERY board (at the top of Figure 6) and
the round DSI display board (at the bottom of Figure 6)
