S800A GNSS Receiver – User Manual 15
3.1.2 Static Surveying Operation
a. Set up the tripod at the measuring station, switch the receiver to
static mode and attach it to the tribrach, centering and leveling it in strict
standard.
b. Measure the height of antenna.
c. Record names of station and receiver, height of receiver,
measurement start time, measurement end time, observation session and
satellite number.
d. Static data logging: Power on the receiver and make sure it’s in
static mode. Receiver starts to search satellites and satellite led starts to be
flashing. When it meets the record demand, the satellite led will be flashing
at default sampling interval, and one flash represents having logged an
epoch.
e. Power off the receiver after finishing data logging, and then transmit
the data and do the indoor data processing. (See detailed operation
procedures in Cube-a Software (V3.0) User Manual.)
