S800A GNSS Receiver User Manual 5
2. S800A Surveying System
S800A surveying system consists of three main components, namely receiver,
handheld and accessories. In the following parts are their introductions.
2.1 S800A Receiver
2.1.1 Receiver appearance
The receiver’s dimension is 146mm*146mm*76mm, weighting 1.2kg, with its
appearance as illustrated in Figure 2-1. The front side is control panel,
consisting of 1 power button and 4 indicators. The bottom are interfaces of
UHF antenna and cables.
Figure 2-1 S800A Receiver
2.1.2 The bottom of Receiver
At the bottom of the receiver is labelled system-unit serial number. The
bottom interfaces are illustrated in Figure2-2, with covers for dust and water
prevention.
