S800A GNSS Receiver – User Manual 17
powered on, it can automatically start static data logging with no need to
reset.
3.2 RTK Dynamic Measurement (Radio)
RTK dynamic measurement (base and rover) has radio mode and network
mode, which two differs from each other in their ways of transmitting
differential signal.
3.2.1 Installation of Base
（1）Set up the tripod in location with known coordinates or unknown
coordinates, level it and attach the receiver on it.
（2）Set up the receiver according to the chosen data link. If using the
internal radio transmission, attach the internal radio antenna into the UHF
antenna port of receiver; if using external radio transmission, connect the
external radio to 5-pin port with 5-pin cable.
（3）Power on the receiver and select base mode.
