STONEX S850+ - 2.3 Bottom view

Stonex S850
+
GNSS Receiver – User Manual 6
2.3 Bottom view
Num.
Item
Description
1
Serial Number
Serial number of the device
2
5/8’ connector
Screw connector for support
3
TNC connector for
UHF antenna
Screw connector for UHF module external antenna. The plastic cover is
held by pressure.
4
Sim card slot
Slot for Nano SIM Card, the card must not have a PIN code, insert the
card while the device is off. The card is locked in by sliding the metal
cover. The plastic cover is held by pressure.
5
5-pin LEMO port
Can be used to connect an external power source. Battery in the device
will not be charged up.
Can also be used for differential correction serial transmission to/from
external devices such as UHF.
