Product description
Instructions for use • S-PILOT
®
• PYB194_EN_V1.0_02-2021_IFU_CE-MDR 14
4
1
2
3 5
6
S-PILOT
®
– Rear view
1 Serial port, e.g. for footswitch 4 SCB sockets
2 Serial port for connecting cable, dia.
3.5mm
5 Power socket
3 Slot for SD memory card 6 Potential equalization connector
Example of a workstation – LAP
Example of a workstation – URO
