Electromagnetic compatibility
Instructions for use • S-PILOT
®
• PYB194_EN_V1.0_02-2021_IFU_CE-MDR 34
Interference im-
munity tests
EN/IEC60601 test
level
Compliance level Electromagnetic envi-
ronment – guidelines
Magnetic field at
the supply fre-
quency (50/60Hz)
acc. to IEC
61000-4-8
30A/m at
50Hz/60Hz
100A/m at
50Hz/60Hz
If image distortion oc-
curs, it may be neces-
sary to position the
product further from
sources of electromag-
netic fields or to install
magnetic shielding. Be-
fore installing the prod-
uct, the electromag-
netic field should be
measured to ensure
that it is sufficiently low.
Radiated, high-
frequency, elec-
tromagnetic field
immunity test acc.
to IEC 61000-4-3
3V/m 80MHz to
2.7GHz
* Refer to table 2 for
wireless proximity HF
field test levels
10V/m 80MHz to
2.7GHz
Immunity to con-
ducted distur-
bances, induced
by high-frequency
fields according
to IEC 61000-4-6
3V
rms
on 150kHz to
80MHz
1kHz 80% AM modu-
lation
6 V
rms
in ISM bands
10 V
rms
on 150kHz to
80MHz
1kHz 80% AM modu-
lation
6 V
rms
in ISM bands
9.4 Table 2 – Test levels for proximity fields from HF
wireless communications equipment
Test fre-
quency
MHz
Frequency
band
MHz
Radio service Modulation Immunity
test level
V/m
Compliance
level
V/m
385 380 – 390 TETRA 400 Pulse modula-
tion 18Hz
27 27
450 430 – 470 GMRS 460,
FRS 460
FM ±5kHz
deviation
1kHz sine
wave
28 28
710 704 – 787 LTE band 13 &
17
Pulse modula-
tion
217Hz
9 9
745
780
810 800 – 960 GSM 800/900,
TETRA 800,
iDEN 820,
CDMA 850,
LTE band 5
Pulse modula-
tion
18Hz
28 28
870
930
1,720 1,700 – 1,990 GSM 1800,
CDMA 1900,
GSM 1900,
DECT,
Pulse modula-
tion
217Hz
28 28
1,845
