Talon SRX - User’s Guide
crosstheroadelectronics.com vexpro.com
Copyright 2017, Cross The Road Electronics, VEX Robotics Inc.
Updated: 2017-02-03
5. Revision History:
2017/2/3 – Added section 2.3.1.
2017/2/2 – Added errata under section 1.4.6.1.
2016/12/3 – Additional FAQ entries added for network topology.
2016/2/1 – Footnotes (1) and (2) added to Electrical /Mechanical specs.
– Section 1.4.6.1 Added.
2016/1/24 – CTR Logo updated.
– Section 2.3. Fault row removed.
2015/2/1 – Added current ratings for Data Port 3.3V/5V to Electrical/Mechanical specs.
– Solid Orange LED state added to Section 2.3. Blink Codes.
– Section 1.3.2.1. CAN Connector added.
– Section 1.3.2.2. CAN Bus Wire Selection.
– Additional content to Section 1.3.4 added.
2015/1/22 – Section 1.4.8. Heat Shrink Use with Breakout Added.
– Quadrature RPM and CPR added to Electrical/Mechanical specs.
– Data Port voltage thresholds and limits added to Electrical/Mechanical specs.
2015/1/12 – AndyMark part numbers added to Sections 1.4.6 and 1.4.7.
2015/1/10 – Section 1.3.4. Firmware Requirements Added
– Section 1.4.7. Analog 5V Encoder (and Limit Switch) Breakout Added
– Section 1.3.1. Adjusted CAN L and CAN H text label positions in figure.
2015/1/2 – Section 1.4.6. Encoder Breakout Added
2014/12/23 – Initial Public Release
