Electrical/Mechanical Specs:
Talon SRX Specs
Outside Dimensions
2.75” x 1.185” x 0.96”
[69.9mm x 30.2mm x 24.4mm]
Weight
0.23 lbf [0.10 kgf] (excluding wiring)
Supported Communication
Protocols
PWM, DWCAN bus (1Mbps)
Nominal Voltage
12V
Min/Max Voltage
6 – 28V
Continuous Current
60A
Surge Current (2 sec)
100A
PWM Input Pulse
(High Time)
1 – 2 ms Nominal
0.6 – 2.4ms max
PWM Input Rate (Period)
2.9 – 100ms
PWM Output Chop Rate
(Switching Frequency)
15.625 kHz
Minimum Throttle (Dead band)
4%
PWM Logic High
Min Voltage Threshold
1V
PWM Logic Low
Max Voltage Threshold
0.4V
PWM Input Min Current
< 1mA
Max Quadrature CPR
(1)
80,000,000 / Peak RPM
Max Quadrature RPM
(1)
80,000,000 / CPR
Logic High
Min Input Voltage
Quad A/B/Idx/Limit Fwd/Rev
2.64V
Logic Low
Max Input Voltage
Quad A/B/Idx/Limit Fwd/Rev
0.66V
Min/Max Voltage
Analog Input
0 – 3.3V
Min/Max Voltage
Quad A/Limit Fwd/Rev
0 – 5V
Min/Max Voltage
Quad B and Quad Idx
0 – 3.3V
(2)
(Talon revision 1.5 and earlier)
0 – 5V (Talon revision 1.6 and on)
Data Port Max Current
3.3V (pin1) : 33mA
5V (pin2) : 50mA
Note 1: This is based on the maximum quadrature edge-to-edge rating of 187.5ns.
Note 2: A late errata on the microcontroller was released after Talon SRX 2015 season production, indicating the Quad B and Quad Idx are
not 5V tolerant. As a result, Talons with revision 1.5 (and earlier) should not use sensor cable/breakouts that allow >3.6V on Quad B or Quad
Idx, as this may damage Talon SRX. See Talon SRX Software Reference Manual (Section 2) for how to detect Hardware Revision. See
Section 1.4.6.1 for the updated breakout solution.
