Objet500 User Guide 2 Safety
DOC-07027 Rev.E 2-2
Safety Features
Stratasys3DprintersaredesignedtocomplywithCEandFCC
standards.Theyareequippedwiththefollowingsafetyfeatures:
Cover Interlock Switch
ThepowersuppliedtotheUVlamp(s),thetrayheaterandthe
motionmotorsisturnedoffwhenthecoverisopened.
Warning
Do not defeat (override) the interlock switch.Doingsocould
resultinseriouspersonalinjury.Iftheinterlockswitchdoesnot
functioncorrectly,donotusetheprinter,andcontactyourservice
provider.
Safety Lock
Thecoverislockedwhiletheprinterisworking.Ifyoudo
managetoliftit,theUVlampsandthemotionmotorsturnoff.
Warning
Do not defeat (override) the safety lock.Doingsocouldresult
inseriouspersonalinjury.Ifthesafetylockdoesnotfunction
correctly,donotusetheprinter,andcontactyourserviceprovider.
UV Screening
ThetransparentsectionofthecoverblocksharmfulUV
radiation,allowingtheoperatortoviewthemodelasitisbeing
made.

Figure2-1 FrontviewoftheObjet500printer
Circuit Breaker
Thepowertotheprinteristurnedoffincaseofelectrical
overcurrent.
Note: Thecircuitbreakerisonlyaccessibletoservice
personnel.
UV-Lamp Overheating
Protection
ThepowersuppliedtotheUVlampandthemotionmotorsis
turnedoffifthetemperaturearoundthelampreaches90°C
(194°F).AlabelontheUV-lampcoverindicatesifthe
temperaturehasexceeded65°C(150°F).

