Stratasys Objet500 - Table of Contents

DOC-07027 Rev.E 6-1
6
Operating and Maintaining the
Objet500 3D Printer
StartingthePrinter 6-3
LoadingModelandSupportCartridges 6-5
ProducingModels 6-6
PreparingthePrinter 6-6
PrinterInterfaceColorKey 6-8
PrintingIndicators 6-9
ResumingProductionAfterPrintinghasStopped 6-10
ChangingthePrintingMaterial 6-12
AdditionalStepsforPrintingWithBio-CompatibleMaterials 6-16
AdvancedSettings 6-16
KeepingthePrinterinIdleMode 6-19
ShuttingDownthePrinter 6-20
ShutdownWizard 6-21
MaintainingthePrinter 6-23
RoutineMaintenanceSchedule 6-23
MaintenanceCounters 6-24
UVLampCheck 6-26
CleaningthePrintHeadsandtheRoller 6-26
CleaningandReplacingtheWiper 6-29
PatternTest 6-32
ImprovingPrintQuality 6-33
CleaningtheRollerWasteCollectorandInspectingtheRoller
Scraper 6-34
ReplacingtheRollerScraper 6-37
AligningthePrintHeads 6-39
Optimizing(Calibrating)PrintHeads 6-43
ReplacingPrintHeads 6-50
