Stratasys Objet500 - Large File Manipulation

Objet500 User Guide 5 Using Objet Studio
DOC-07027 Rev.E 5-52
Large File
Manipulation
Ifyouneedtoworkwithadetailedmodelthatiscomposedofalargenumber
ofpolygons,youcanspeedupitsdisplayandmanipulationinObjetStudioby
reducingthenumberofpolygonsonthescreen.Althoughthismayreduce
theresolutiononthescreen,ithasnoaffectontheprintedmodels.
Figure5-65Objectdisplayedwithoutpolygonreduction
Figure5-66Objectdisplayedwithonlyfivepercentofitspolygons
showing
Tousepolygonreduction:
1. FromtheToolsmenu,selectOptions.
or—
FromtheObjetStudioCommandsmenu ,clickOptions.
