Strong LEAP-S3 User Manual

9
Step 1: Language
Select your preferred language on the Welcome Page.
English
Afrikaans
Bahasa Melayu
Català
Čeština
Dansk
...
Welcome
Step 2: Location Settings
Select the region or country where you are using this Google TV Box.
Armenia
Argentina
Australia
Autria
Azerbaijan
Bahrain
...
Select
your country
Step 3: Set up with the Google Home App
Set up the TV Box by downloading / opening the Google Home app on your phone.
Please, scan the QR code on your phone and follow the instruction to start this Google home.
Alternative, Start the set up on TV screen to type manually way by pressing down button to start with.
Please, follow the instruction on your TV screen.
Set up with
the Google Home
App
Download and open the Google Home App
on your phone to get strated. Scan the QR code.
Set up on TV instead
Step 4: Wi-Fi
If you not are connected with RJ45 cable to internet will Wi-Fi setup appear.
Select here to your Wi-Fi Network.
1600_2.4G
1600_5G
Super_2.4Ghz
Kapsalon
Other network
...
Select your
Wi-Fi network

Strong LEAP-S3 Specifications

Video and Audio Decoding

video resolution	4Kp60, 1080p60
audio decoding sample rates	32KHz to 192KHz
audio decoding formats	Dolby Digital MS12, Dolby ATMOS, AAC LC, AAC LC + SBR, AAC 5.1, HE AAC Level 2 & Level 4, MPEG Audio Layers 1, 2 & 3, MPEG-4 Audio

System and Memory

android version	11
chipset	Amlogic S905Y4
cpu	Amlogic S905Y4 Quad Core Cortex-A35, 2.0 GHz
gpu	ARM G31 MP2 OpenGL ES 3.2 Graphics engine
sdram	LPDDR RAM: 2 GB
flash memory	eMMC: 16 GB

Connectors

hdmi version	2.1
ethernet	RJ 45, 10/100
usb	1x USB 2.0 Type A, 500mA
s/pdif	Optical
dc input	12 V, 1 A

General Data

wi-fi	IEEE 802.11b/g/n, 2.4 GHz; IEEE 802.11a/n/ac, 5 GHz
bluetooth	5.0 (LE 4.2)
power supply	100 - 240 V AC, 50/60 Hz
input voltage	DC 12 V, 1 A
power consumption working	7 W (max.)
operating temperature range	0 ~ +40 °C
storage temperature	-10 ~ +70 °C
dimensions	96 x 96 x 20, 8 mm
weight	179 g
