Strong LEAP-S3 User Manual

11
Step 11: Welcome to Google TV
A walkthrough of the features of your device
Your Google TV
experience
is ready
Start exploring
Click on DONE after the walkthrough to start using your device. You are now ready to begin
5. SETTINGS
Press the setting button to open Settings
Select Settings to check the device information, add/remove accounts and make changes to the
system settings.
Settings
Set your device name
Display & Sound
Network & Internet
Account & Sign-in
Privacy
Advanced settings
Advanced settings
Display and sound
Select HDMI-CEC for setup connections and adjustments trough CEC (Consumer Electronics Control).
Select Display settings for selection of screen formats and resolutions.
Select Sounds settings for setup of Dolby and audio formats.
Network and Internet
Under Network Settings, select and enable Wi-Fi in order to connect to the network.
Once the device scans and lists nearby Wi-Fi networks, select the appropriate network name, if required put in the password and
select Connect.
Hide password

Select  to continue
Enter password
for 1600_2.4GHz
l

Strong LEAP-S3 Specifications

Video and Audio Decoding

video resolution	4Kp60, 1080p60
audio decoding sample rates	32KHz to 192KHz
audio decoding formats	Dolby Digital MS12, Dolby ATMOS, AAC LC, AAC LC + SBR, AAC 5.1, HE AAC Level 2 & Level 4, MPEG Audio Layers 1, 2 & 3, MPEG-4 Audio

System and Memory

android version	11
chipset	Amlogic S905Y4
cpu	Amlogic S905Y4 Quad Core Cortex-A35, 2.0 GHz
gpu	ARM G31 MP2 OpenGL ES 3.2 Graphics engine
sdram	LPDDR RAM: 2 GB
flash memory	eMMC: 16 GB

Connectors

hdmi version	2.1
ethernet	RJ 45, 10/100
usb	1x USB 2.0 Type A, 500mA
s/pdif	Optical
dc input	12 V, 1 A

General Data

wi-fi	IEEE 802.11b/g/n, 2.4 GHz; IEEE 802.11a/n/ac, 5 GHz
bluetooth	5.0 (LE 4.2)
power supply	100 - 240 V AC, 50/60 Hz
input voltage	DC 12 V, 1 A
power consumption working	7 W (max.)
operating temperature range	0 ~ +40 °C
storage temperature	-10 ~ +70 °C
dimensions	96 x 96 x 20, 8 mm
weight	179 g
