Strong LEAP-S3 User Manual

7
2.5Installing the batteries
Fig. 4
Open the cover on the remote control and insert 2x AAA batteries into the compartment. The correct position of batteries polar
diagram is shown inside the batteries compartment.
1. Open the cover.
2. Insert the batteries.
3. Close the lid.
WARNING: The batteries should not be recharged, disassembled, electrically short- circuited, be mixed or used
with other types of batteries.
3. CONNECTION GUIDE
Refer to the diagram below for connecting your Google TV Box to the HDMI input of TV.
NOTE: Before getting started, please turn o all devices to be connected.
Fig. 5
12V 1A

Strong LEAP-S3 Specifications

Video and Audio Decoding

video resolution	4Kp60, 1080p60
audio decoding sample rates	32KHz to 192KHz
audio decoding formats	Dolby Digital MS12, Dolby ATMOS, AAC LC, AAC LC + SBR, AAC 5.1, HE AAC Level 2 & Level 4, MPEG Audio Layers 1, 2 & 3, MPEG-4 Audio

System and Memory

android version	11
chipset	Amlogic S905Y4
cpu	Amlogic S905Y4 Quad Core Cortex-A35, 2.0 GHz
gpu	ARM G31 MP2 OpenGL ES 3.2 Graphics engine
sdram	LPDDR RAM: 2 GB
flash memory	eMMC: 16 GB

Connectors

hdmi version	2.1
ethernet	RJ 45, 10/100
usb	1x USB 2.0 Type A, 500mA
s/pdif	Optical
dc input	12 V, 1 A

General Data

wi-fi	IEEE 802.11b/g/n, 2.4 GHz; IEEE 802.11a/n/ac, 5 GHz
bluetooth	5.0 (LE 4.2)
power supply	100 - 240 V AC, 50/60 Hz
input voltage	DC 12 V, 1 A
power consumption working	7 W (max.)
operating temperature range	0 ~ +40 °C
storage temperature	-10 ~ +70 °C
dimensions	96 x 96 x 20, 8 mm
weight	179 g
