Problem Possible reason Remedy
The receiver switches o after
3 hours of no commands of the
remote control
The power saving Auto standby
function is activated
Switch o the Auto Standby/
Daydream function.
Forgotten your PIN code Default PIN is 1234 Contact your local Service
Hotline or send an email to our
support via www.strong.tv
The external USB HDD does not
start.
The power consumption is too
high.
Connect an extra power supply
adapter to your USB HDD device.
Timeshift intermittent playback Too many USB devices
connected
Disconnect e.g. the USB camera
A recording does not start HDD is not selected in the menu Select the recording device in
the DVR settings menu.
9.0 TECHNICAL SPECIFICATIONS
Tuner & Demodulator
Frequency range DVB-S2: 950~2150 MHz
Frequency range DVB-T2: 174 MHz ~ 230 MHz/474 MHz ~ 858 MHz
Frequency range DVB-C: 113 MHz ~ 858 MHz
Demodulator modes: DVB-T2, DVB-S2, DVB-C
Demodulator DVB-S2: QPSK/8PSK; Symbol rate up to 55 Mbps
Demodulator DVB-T2: QAM modes: 4, 16, 64, 256 (with or without rotation)
Bandwidths: 1.7, 5.0, 6.0, 7.0, 8.0 MHz
FFT Sizes: 1K, 2K, 4K, 8K, 16K, 32K±600 KHz frequency
Demodulator DVB-C: 16QAM, 32QAM, 64QAM, 128QAM, and 256QAM; Symbol
rate up to 7.0 Mbps
Video decoder
Video compression: H.264/AV, H.265/HEVC
Video resolution: 4K@60fps 1080p/1080i, 720p
Audio decoder
Audio support: MEPG, OGG, OGA, FLAC, ALAC, Ape, M4A, RM, MPEG-1
layer1/2 (Dolby® Digital, Dolby® Digital Plus*, WMA, WMA
Pro, WMV optional)
*Dolby Digital Plus, Dolby Digital and the double-D symbol are registered trademarks of Dolby Laboratories
System & Memory
Android Version: 7.1
Chipset: Amlogic S905D-B
CPU: Quad Core Cortex-A53 2.0 GHz
GPU: Mali-450MP
SDRAM: DDR3, 1 GB
Flash: eMMC: 8 GB
Connectors
ANT IN/CABLE IN IEC-169 Female
SAT IN F-type
S/PDIF (coax.)
23
English
