4. Controls/Functions
❶ ❸ ❷ ❹ ❻ ❺ h
4.1 Front Panel
❶ Standby/Power on Indications Lamp: Flashes red light in ‘Standby’
mode and shows no light in ‘Power ON’ mode.
❷ Power: Switches the receiver between ‘Standby’ and ‘Power
ON’ modes. ❸ -❹ CH. (▲/▼): To switch channels or change the
cursor position on the application screen.
❺ USB: To connect USB devices such as Memory stick or external
Hard Disk Drive.
❻ Smart Card Reader: Insert smart card for encrypted channel
access.
