8. Specifications
System
capabilities
Fully DVB compliant
satellite
Connector IEC 169-24, female
LNB/Tuner input
Frequency range Signal
level LNB supply LNB
switch control DiSEqC
950MHz ~ 2150MHz -65dBm ~ -25dBm DC
13/18V, max 400mA 22KHz Ver
1.0/1.1/1.2/USALS Compatible
Demodulator
Front end DVB-S/S2 QPSK, 8PSK, 16APSK, 32APSK
Symbol rate DVB-S : 2~45Msps
DVB-S2 : 10~30Msps(QPSK)
10~30Msps(8PSK) 36Msps(16APSK),
27Msps(32APSK)
SCPC and MCPC Capable
Spectral inversion Auto conversion
System resource
Processor 32bit processor (550MHz, 850DMIPS)
DDR3 128Mbyte
FLASH 8Mbyte
ideo decoder
MPEG 2 MPEG-2, MPEG-4, H.264
Data Rate up to 15M bits/s
Resolution
1920 X 1080P/i, 1280 X 720P, 720 X
576P/i
Video format PAL
Aspect Ratio 4:3,16:9
Teletext
DVB compliant
MPEG Audio
MPEG 1 layer I/II, MPEG
2 layer II, AC3 Dolby
Digital
Type Mono, Stereo, Joint Stereo
Sampling rates 32, 44.1 and 48 KHz
Remote control
Code NEC-IR
Operating condition up to 7 Meter
USB
USB Supply DC 5V Max 500mA
