DiSEqC1.1: To select the correct port from up to 16 (if available) for the corresponding
LNB. Uncommitted DiSEqC switches in cascade can be used with this
protocol.
22KHz: Auto is the setting for a Universal LNB
Polarity Option are: Auto, H for horizontal and V for vertical.
It will switch the LNB power as required by the transponder list.
For universal and SatCR LNB's, the setting is best left on Auto
For Motor Dish only:
LNB Freq: Press tu or OK to show the list of LNB types. Normal use for a motorized
dish is the universal LNB (09750/10600 MHz) – the most used on the market.
Select with pq and OK the LNB you are using
Motor Type Options are DiSEqC 1.2 and GOTOX (Also known as USALS or DiSEqC 1.3).
Depending on your motor drive, select the correct setting.
7.1.2 DiSEqC 1.2
DiSEqC 1.2 is a protocol for motor-driven dishes, the dish/motor-combination itself needs to be aligned
due South (North for Southern hemisphere) at its reference position at 0°. It requires to manually search
and store every satellite individually.
Refer to the manual of your motor-drive for more detailed information. Modern motor drives have
usually also the capability of the enhanced DiSEqC 1.3 protocol, which would be preferred, since it can
nd satellite positions automatically, relative to a geographical location.
Move the motor to the right position for locking the signal like explained below.
Satellite Selected the Satellite you want to search for.
Transponder Select a known transponder on the satellite to help you nd it.
Also use the signal intensity and signal quality bars to nd the satellite.
Position No.&Save Select on which memory position the found satellite should be stored.
Go to X When just setting up the dish, move the motor to its reference point, at 0
degrees. Select Reference and press OK to move.
Select and press OK to see a list with already stored satellites.
Select a number from the list and press OK to move the dish to that position.
Save Select Save and press continuously either t or u, to move the dish to
the position where you suspect the Satellite is. When found (for example,
conrmed by a Signal on the bars), let go of the t or u button. With short
presses on the t or u buttons, you can peak the dish. Then Press OK (while
still on save). Conrm the position (already selected in Go to X to be stored.
NOTE: The movement of the Dish can be stopped by pressing OK or  on the RCU.
NOTE: The dish might get misaligned over time. Move the dish to its reference
point at 0 degrees and select Recalculation. Conrm the pop-up to
recalculate positions.
