Limit Setup To setup the limits the dish should not exceed when moving, in case of
physical obstructions. Default is disable limit (not active). If needed, the motor
can physically be brought to its 0° reference position, to align the dish south
when in the northern hemisphere (or north for southern hemisphere) rst.
To set the West Limit, use tu to select West Limit, then press shortly t to
move the dish West. Press t again or OK when the limit is reached.
Press OK again. A pop-up message will conrm: West Limit is set.
To set the East Limit, use tu to select East Limit, then press shortly u to
move the dish East. Press u again or OK when the limit is reached. Press OK
again. A pop-up message will conrm: East Limit is set.
To disable the limits, select disable limit, then limit setup and press OK. A pop-up message will conrm:
disable limit is set.
When all settings have been made, press  to save the data and leave the window.
GotoX
(also known as DiSEqC 1.3 or USALS)
GotoX is an automated system for nding satellites with a motor driven dish. It is an enhancement of the
DiSEqC 1.2 protocol, where it was still needed to manually search and store every satellite individually.
With DiSEqC 1.3 every satellite position is automatically calculated for a dened geographical location on
earth. Only this location is needed to be entered and stored in to the box, in conjunction with a GotoX
capable motor drive, all (pre-installed) satellites can easily be found. The dish/motor-combination itself
needs to be aligned due South (North for Southern hemisphere) at its reference position at 0°. Refer to
the manual of your motor-drive for more detailed information.
LNB Frequency Select the correct LNB which is placed in your Satellite Dish.
Motor Type Select GotoX with the tu buttons.
Local Longitude Find out the coordinates of the location where the dish is installed. Consisting
of degrees on northern or southern hemisphere and eastern or western
hemisphere.
When you rst enter, choose E or W with the tu buttons.
Then use the 0 ~ 9 buttons to enter the coordinate.
Local Latitude When you rst enter, choose N or S with the tu buttons.
Then use the 0 ~ 9 buttons to enter the coordinate.
NOTE: The location setting only needs to be entered once and is valid for all
satellites.
Delete All Turns the entered Longitude and Latitude to 0.00
Motor Setting To make a test with the moving dish if the selected satellites in the satellite list
indeed can be found.
Limit Setup To setup the limits the dish should not exceed when moving, in case of
physical obstructions. Default is disable limit (not active). If needed, the motor
can physically be brought to its 0° reference position, to align the dish South
when in the northern hemisphere (or north for southern hemisphere) rst.
To set the West Limit, use tu to select West Limit, then press shortly t to
move the dish West. Press t again or OK when the limit is reached.
Press OK again. A pop-up message will conrm: West limit is set.
