Operation
Connecting the litter to the base
Note: You can attach the Model 6100-031-000 knee gatch litter and the Model 6100-033-000 flat foot section litter
in either direction.
To connect the removable litter to the base (Figure 1-8 on page 1-21):
1. Lower the litter onto the base.
2. Align the roller guides on the litter with the center base tube.
3. Push the litter forward toward the head end to attach to the litter retention brackets.
4. Make sure that you lock the litter onto the base before you release your grip on the litter.
Figure 1-8: Connecting and removing the litter
Removing the litter from the base
To remove the removable litter from the base (Figure 1-8 on page 1-21):
1. Push and hold the blue litter release button that is located at the foot end of the base.
2. Pull the litter toward the food end of the cot to remove the litter from the litter retention brackets.
3. Lift to remove the litter from the base.
