RCC-02/-03
64 V4.4.0 User manual
14.11.5.13 AC-In present {1235} {1343}
Activates the auxiliary contact if a voltage is present at the AC-In input. This condition is independent
of the state of the transfer relay.
14.11.5.14 Transfer relay drawn {1236} {1344}
Activates the auxiliary contact if the transfer relay is drawn.
14.11.5.15 AC-Out present {1237} {1345}
Activates the auxiliary contact if a voltage is present at the output of the Xtender inverter/charger.
14.11.5.16 Battery charging in bulk charge phase {1238} {1346}
Activate the auxiliary contact if the battery is in bulk charge phase.
14.11.5.17 Battery charging in absorption phase {1239} {1347}
Activates the auxiliary contact if the battery is in absorption phase. If the periodic extended
absorption function is activated, the contact is also activated in this phase.
14.11.5.18 Battery charging in equalization phase {1240} {1348}
Activates the auxiliary contact if the battery is in equalization phase.
14.11.5.19 Battery charging in floating phase {1242} {1350}
Activates the auxiliary contact if the battery is in maintenance phase. If the extended reduced
floating function is activated, the contact is also activated in this phase.
14.11.5.20 Battery charging in reduced floating phase {1243} {1351} and
14.11.5.21 Battery charging in periodic absorption phase {1244} {1352}
You can activate the auxiliary contacts on the reduced floating phase and the periodic absorption
phase.
14.11.5.22 INSTALLER - Quota AC-In active {1601} {1602}
When the minigrid mode is activated and the AC-In energy quota is reached the corresponding
auxiliary relay is activated.
14.11.6 Contacts activated by the battery voltage {1245} {1353}
These configurations allow activation of the auxiliary contacts if the battery voltage passes below a
selected voltage during a period that is configurable as well. Three voltages linked to three durations
are configurable to activate the auxiliary contact.
The auxiliary contact will only be activated after the battery exceeds again a certain voltage value
and also after a duration, both independently of the activation parameters.
This voltage and this duration are programmable too.
 Dynamic compensation of the thresholds {1288} {1354}
 Voltage 1 active {1246} {1355}
 Voltage 1 {1247} {1356}
 Duration 1 {1248} {1357}
 Voltage 2 active {1249} {1358}
 Voltage 2 {1250} {1359}
 Duration 2 {1251} {1360}
 Voltage 3 active {1252} {1361}
 Voltage 3 {1253} {1362}
 Duration 3 {1254} {1363}
