Studer RCC-02 User Manual

Studer Innotec SA
RCC-02/-03
User manual V4.4.0 23
10.7 DATA LOGGER {5057}
10.7.1 Data logger enabled {5101}
Activates the data logger. There are three possible values: Automatic /Yes /No. In automatic mode
the data logger is activated on all RCC, Xcom-LAN and Xcom-GSM.
Every day at midnight a CSV file is created on the SD card in the directory CSVFILES, in the subfile
LOG. This file contains the recordings minute by minute of the main system electrical values. This file
can reach the size of 1MB. Make sure that there is enough available space on the SD card. If there
is not enough space while creating the CSV file the datalogger will automatically delete the 30 oldest
log files from the SD card.
The remote control writing system is not guaranteed for all kinds of SD cards. It does
not work with cards formatted with the FAT32 system. The cards with a size over 2GB
are not compatible.
In case of software updating of the system, the data of the day are lost.
You will find more information and the easiest method to exploit these data in the
chapter „Data logger“, p. 35 of this document.
10.7.2 Backup of the current day data {5059}
If you want to have the data of the current day, you can force the recording of the data of the day
with this function. The file then created will only be partial and a new file with all data will be
generated at midnight.
10.8 BACKUP AND RESTORING {5013}
The different options of this menu allow you to do a safety backup of your system or various actions
in relation to the SD card.
The remote control RCC is not compatible with all types of SD cards. Cards with FAT32
formatting system are not supported; therefore cards with more than 2GB can not be
used.
10.8.1 Backup of all files {5041} (System backup)
This function enables to save in one operation all files linked to the remote control:
 The events history files
 The remote control parameter files
 The Xtender parameter files
 The VarioTrack parameter files
 The VarioString parameter files
 The BSP parameter files
10.8.2 Restore all files {5068} (System recovery)
This parameter restores all Xtenders, BSPs and remote controls settings saved with the parameter
"Backup of all files {5041}".
Caution: when using this function with a 9 Xtender system, the process of copying files
can last up to 15 minutes.
