Studer Innotec SA
RCC-02/-03
34 V4.4.0 User manual
12.21 (060) (061) WARNING: TIME SECURITY FOR AUXILIARY CONTACTS
The maximum duration that you have selected for the relay activation with the parameter {1514},
{1515} is reached and the activation conditions are still present. The contact will not be reactivated
as long as the conditions are present. Therefore there is a risk that the auxiliary contact remains locked
in this position unless you reset this alarm.
Method: reset manually this alarm with the corresponding parameter ({1512}AUX1, {1513}AUX2) by
deactivating and then activating it.
Use this function with care and only as a security.
12.22 (062) WARNING: GENSET, NO AC-IN COMING AFTER AUX COMMAND
The genset start has been driven by the auxiliary contact but there is no voltage at the Xtender input.
Method: check that the genset runs and that its connection to the Xtender has not been interrupted.
12.23 STORED EVENTS
Events are stored in the remote control. Any system not permanently connected to a remote control
does not store the events.
To access the event history via one of the basic displays,
change the screen by using the keys UP and DOWN until
the “event history” screen appears and then validate
using the key SET.
The number shown at the top right indicates the
message number. In a system with several Xtenders, the
events are presented in chronological order and the
lower line indicates the Xtender to which the event refers.
Each event is recorded as well as the date and time of its
occurrence. The keys UP and DOWN allow you to view all
the events that have occurred.
Where there is a system with multiple Xtenders, each
message also contains the number of the Xtender that
has generated the message.
Quit the message display by using the key ESC.
These messages can be exported on a SD card, which allows their transmission or their
use on a computer.
