PARTS LISTS & EXPLODED VIEWS
4-20
1. 6200720 Screw, #8-18 x ½ PH Truss Hd.
2. 0183580 Drawer Panel Bracket, Upper
3. 6200110 Screw, #10-12 x 5/8 Truss SS
4. 3211520 Upper Drawer Gasket
5. 0183590 Drawer Panel Bracket, Lower
6. 4131740 Lower Drawer Front Assy.
7. 3211540 Lower Drawer Gasket
8. 4131780 Lower Drawer Tub
9. 3601350 Lower Drawer Divider
10. 4202020 Drawer Tub Seal
11. 4202060 Upper Drawer Wire Channel
12. 4131760 Upper Drawer Tub
13. 3470320 Crisper Lid Assy.
14. 4202030 Drawer Control Panel Assy.
15. 4131730 Upper Drawer Front Assy.
16. 3601340 Upper Drawer Divider
17. 6200780 Screw, #10-24 x ½ PH Hex
Washer
700BR DOOR VIEW
