Sub-Zero Classic Series Installation Guide

10 | English
KICKPLATE INSTALLATION
Reinstall the drain pan and verify it is in the proper position.
Install the kickplate using the magnets to attach it to the
brackets on the inside of each roller base. Refer to the
illustration below. The kickplate must be removable for
service. The floor cannot interfere with removal. Refer
to the label mounted on the kickplate support for height
clearance.
To turn power on to the unit, touch and hold
on the
control panel.
Kickplate installation
Installation
Completion
GRILLE INSTALLATION
Install the grille assembly and check for proper fit. The
grille is designed to rest on the upper door hinge to mini-
mize the reveal between the top of the door and bottom
of the grille. To eliminate interference, the grille height can
be adjusted. Loosen the four grille adjustment screws (two
on each side) and adjust the grille height as needed. Refer
to the illustration below.
ANCHORING
After the unit has been leveled and door adjustment com-
pleted, anchor the unit to the opening to ensure a proper
fit and secure installation.
To anchor the top of the unit, open the grille and install the
screws provided through the grille frame into cabinetry.
There are several hole locations. Refer to the illustration
below. Check for proper door clearance by opening the
door.
To anchor the bottom of the unit, drive a screw through
the side hole inside each roller base assembly. The screw
will need to go in at an angle to attach properly. Refer to
the illustration below. Additional material may be needed
behind the cleat to ensure sucient anchoring.
CAUTION
If the screws provided are not suitable for the instal-
lation, use adequate screws.
WARNING
To avoid a hazard due to instability of the appliance,
it must be fixed in accordance with the instructions.
ANCHORING
SCREWS
ANCHORING
SCREW
Top anchoring Bottom anchoring
Grille height adjustment
FRONT
GRILLE SCREW
GRILLE
ADJUSTMENT
SCREWS
BACK
GRILLE
SCREW
90° DOOR STOP
The door opens to 110°. A 90° door stop is provided with
the unit (located behind the grille). Additional 90° door
stop kits are available through an authorized Sub-Zero
dealer.
WARNING
Follow all city and state laws when storing, recycling,
or discarding unused refrigerators and freezers.

Sub-Zero Classic Series Specifications

General

Series	Classic Series
Brand	Sub-Zero
Refrigeration Type	Dual Refrigeration
Lighting	LED
Defrost System	Automatic
Air Purification	Yes
Finish	Stainless Steel
Energy Star Certified	Yes
Width	36 inches
Height	84 inches
Configuration	Side-by-Side
Preservation System	Air Purification
Ice Maker	Yes
Door Finish	Stainless Steel
