12-12
Specifications/Fuses
and
circuits
&
Fuse
panel
located
in
the
engine
compartment
A)
Main
fuse
Fuse
panel
Fuse
rating
Circuit
1
30A
.
ABS
unit
.
Vehicle
Dynamics
Con-
trol
unit
2
25A
.
Main
fan
(cooling
fan)
3
25A
.
Sub
fan
(cooling
fan)
4
Empty
5
Empty
6
30A
.
Headlight
(low
beam)
7
15A
.
Headlight
(high
beam)
8
20A
.
Back-up
9
15A
.
Horn
10
25A
.
Rear
window
defogger
.
Mirror
heater
1
1
15A
.
Fuel
pump
12
20A
.
Continuously
variable
transmission
control
unit
13
7.5A
.
Engine
control
unit
14
15A
.
Turn
and
hazard
warn-
ing
flasher
15
15A
.
T
ail
and
illumination
re-
lay
16
7.5A
.
Alternator
446
448
