Section 7
ILLUSTRATIONS AND PARTS LIST
44
7.7 COMPRESSOR COOLING AND LUBRICATION SYSTEM (AIR---COOLED, LS---12 SERIES 40 AND
50HP)
key part
number description number quantity
1 cooler, fluid and aftercooler assembly 250038---657 1
2 elbow, tube---m 1 1/2” x 1 1/2” 810524---150 1
3 tube, 1 1/2” 250018---259 1
4 bushing, reducing 3/4” x 1/2” 802103---020 1
5 tube, 1 1/2”od 250018---251 1
6 connector, tube 1” x 1” 810216---100 3
7 tube, 1” 250039---986 1
8 elbow, tube 1” x 1” 810516---100 3
9 tube, 1” 250038---497 1
10 valve,fluidstop1”
(I)
016741 1
11 elbow, tube 5/16” x 1/4” 810505---025 1
12 tubing, 1/4” 841015---004 10 ft.
13 nipple, pipe 1” x close 822216---000 3
14 tubing, 5/16” stainless steel 841215---005 2.7 ft.
15 connector, tube---m 1 1/4” x 1 1/4” 810220---125 2
16 bushing, reducing 1 1/4” x 1” 802105---040 1
17 connector, tube---m 1/4” x 1/4” 810204---025 2
18 filter, fluid
(II)
250025---522 1
19 tube, 1 1/4” 250018---246 1
20 plug, pipe 1/2” 807800---020 1
21 tee, reducing 1 1/2” x 1 1/4” x 1” 802206---054 1
22 nipple, pipe 1 1/2” x close 822224---000 2
23 valve, thermal
(III)
014512 1
24 connector, tube---m 1 1/2” x 1 1/2” 810224---150 7
25 bushing, reducing 1 1/2” x 1” 802106---040 1
26 tube, 1 1/2” 250018---376 1
27 tee, reducing 1 1/2” x 1/2” x 1 1/2” 802206---026 1
28 nipple, pipe 1/2” x 4” 822108---040 1
29 valve, globe 1/2” 041007 1
30 washer, springlock 1/2” 837508---125 3
31 capscrew, hex 1/2”---13 gr5 828608---150 3
32 bracket, air connector and condenser drain 250017---233 1
(Continued on page 47)
(I)
For maintenance on fluid stop valve no. 016741, order repair kit no. 001684.
(II)
For maintenance on fluid filter no. 250025---522, order repair kit no. 250025---526.
(III)
For maintenance on thermal valve no. 014512, order repair kit no. 001168.
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR.
