Section 7
ILLUSTRATIONS AND PARTS LIST
86
7.17 ELECTRO---PNEUMATIC CONTROL SYSTEM (LS---12 AND LS---16 SERIES)
key part
number description number quantity
1 bushing, conduit plastic 1/2” 848815---050 1
2 locknut, conduit 1/2” 847200---050 4
3 nipple, chase conduit 1/2” 847815---050 1
4elbow,90
_
1/2” 846915---050 1
5 switch, pressure 0---150# Ni 040694 1
6 capscrew, hex serrated washer 5/16” x 3/4” 829705---075 2
7 nut, hex plated #10---32 825801---130 2
8 washer, springlock regular #10 838502---047 2
9 bracket, pressure switch support 250018---146 1
10 screw, machine rd head #10---32 x 1/2” 831702---050 2
11 tubing, 1/4” 841015---004 60 ft.
12 tee, tube---m 1/4” x 1/4” x 1/4” 810904---025 2
13 tee, pipe galvanized 1/4” 804415---010 3
14 nipple, conduit 1/2” x 1 1/2” 250007---169 1
15 connector, tube---m 1/4” x 1/4” 810204---025 1
16 valve, check 1/4” 049905 1
17 nipple, pipe galvanized xs 1/4” x close 823204---000 7
18 elbow, pipe galvanized 90
_
1/4” 803515---010 3
19 elbow, tube---m 1/4” x 1/4” 810504---025 2
20 valve, solenoid 1/4” 3---way 150#
(I)
250038---674 1
21 strainer, v --- type
(II)
241771 1
22 valve, differential pres regulator 1/4”npt
(III)
406929 1
23 orifice, pipe plug 1/4” 232874 1
24 connector, tube---m 1/4” x 1/8” 810204---012 1
25 nut, hex flanged plated 5/16”---18 825305---283 2
26 switch, high discharge pressure 135 psi nc 250017---991 1
27 nipple, galvanized xs 1/4” x 1 1/2” 823104---015 1
28 bracket, valve support 250030---037 1
29 screw, pan hood #8---32 x 3/8” 835601---038 2
30 washer, lock int tooth #10 838402---025 4
31 screw, self tap #10---24 x 1/2” 835602---050 2
(I)
For maintenance on solenoid valve no. 250038---674, order repair kit no. 250038---673 (valve) or no.
250031---738 (coil).
(II)
For maintenance on v---type strainer no. 241771, order repair kit no. 241772.
(III)
For maintenance on pressure regulator no. 406929, order repair kit no. 041742.
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR.
