Section 7
ILLUSTRATIONS AND PARTS LIST
88
7.18 ELECTRIC CONTROL BOX ASSEMBLY (LS---12 AND LS---16 SERIES)
key part
number description number quantity
1 support, starter --- left hand 250017---978 1
2 support, starter --- right hand 250017---977 1
3 bushing, snap 250042---243 1
4 gasket 250019---557 1
5 MFV starter, assembly Size 3 N12 250038---564 1
S
MFV starter, assembly Size 4 N12 250038---565 1
S
MFV starter, assembly Size 5 N12 250038---566 1
6 washer, plaint steel 3/8” 837206---071 8
7 capscrew, hex head 3/8”---16 x 1 1/4” gr8 828606---125 4
8 capscrew, hex gr5 1/2”---13 x 1 1/2” 828608---150 11
9 nut, hex 3/8”---16 824206---337 4
10 block, terminal 250041---102 10
S
block, end adapter 250041---103 1
11 elbow, 45
_
conduit 846500---050 1
12 conduit, csa flex 1/2” 846315---050 2 ft.
13 wire, neoprene so #12---4 850604---012 6 ft.
14 grip, cord for so 12/4 250018---497 2
15 locknut, conduit 1/2” 847200---050 1
16 washer, springlock regular 3/8” 837506---094 4
17 bushing, 1 1/2” 848815---150 1
18 locknut, 1 1/2” 847200---150 1
1 9 fuse Consul t Fac tor y
20 grip, cord for g---gc #4 250014---557 1
S
grip, cord for g---gc 250014---559 2
21 cord, type g---gc #4ga 250014---306 4 ft.
S
cord, type g---gc #2 ga 250014---308 4 ft.
22 washer, springlock 1/2” 837508---125 11
23 fuse, primary 208V (starter size 3) 250026---649 2
S
fuse, primary 208V (starter size 4 & 5) 250006---652 2
S
fuse, primary 230V (starter size 3) 250026---649 2
S
fuse, primary 230V (starter size 4 & 5) 250026---651 2
S
fuse, primary 460V (starter size 3) 250026---644 2
S
fuse, primary 460V (starter size 4 & 5) 250026---648 2
S
fuse, primary 575V (starter size 3) 250026---643 2
S
fuse, primary 575V (starter size 4 & 5) 250026---646 2
S
fuse, secondary 115V (starter size 3) 250026---644 1
S
fuse, secondary 115V (starter size 4 & 5) 250026---650 1
(Continued on page 91)
PLEASE NOTE: WHEN ORDERING PARTS, ALWAYS INDICATE SERIAL NUMBER OF COMPRESSOR.
