Sun Microsystems GDM-FW9010 - Timing Specification

GDM-FW9010(E) 6
TIMING SPECIFICATION
PRIMARY MODE PRIMARY
MODE AT PRODUCTION MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6
RESOLUTION (HXV) 1920 X1200 - 1600 X 1000 1600 X 1000 1440 X 900 1280 X 800
CLOCK 219.375 MHz - 170.100 MHz 135.000 MHz 135.000 MHz 101.250 MHz
— HORIZONTAL —
H-FREQ 87.192 kHz - 79.934 kHz 68.598 kHz 71.809 kHz 64.490 kHz
usec - usec usec usec usec
H. TOTAL 11.469 - 12.510 14.578 13.926 15.506
H. BLK 2.717 - 3.104 2.726 3.259 2.864
H. FP 0.109 - 0.188 0.296 0.296 0.198
H. SYNC 1.039 - 1.270 1.007 1.185 1.126
H. BP 1.568 - 1.646 1.422 1.778 1.541
H. ACTIV 8.752 - 9.406 11.852 10.667 12.642
— VERTICAL —
V. FREQ(Hz) 70.316 Hz - 76.055 Hz 66.023 Hz 76.068 Hz 76.230 Hz
lines - lines lines lines lines
V. TOTAL 1240 - 1051 1039 944 846
V. BLK 40 - 51 39 44 46
V. FP 1 - 2 2 2 3
V. SYNC 3 - 3 5 3 7
V. BP 36 - 46323936
V. ACTIV 1200 - 1000 1000 900 800
— SYNC —
INT(G) NO - NO NO NO NO
EXT(H/V)/POLARITY NO N/N - NO N/N NO N/N NO N/N NO N/N
EXT(CS)/POLARITY YES - YES YES YES YES
INT/NON INT NON INT - NON INT NON INT NON INT NON INT
