GDM-FW9010(E) 6-1
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
The components identified by [ in this
manual have been carefully factory-selected
for each set in order to satisfy regulations
regardin X-ray radiation.Should replacement
be required, replace only with the value
originally used.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
RESISTORS
• All resistors are in ohms
• F : nonflammable
When indicating parts by reference
number, please include the board name.
Les composants identifiés par la marque !
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
The components identified ! marked are
critical for safety.
Replace only with the part number specified.
