GDM-FW9010(E) 6-38
No. # Board Type ! /
*
Ref.No. Part No. Descrption Remarks-1 Remarks-2 Difference
1117 H RESISTOR R815 1-216-675-91 METAL CHIP 10K 0.5% 1/10W
1118 H RESISTOR R821 1-215-401-11 METAL 150 1% 1/4W
1119 H RESISTOR R822 1-215-413-00 METAL 470 1% 1/4W
1120 H RESISTOR R823 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
1121 H RESISTOR R824 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
1122 H RESISTOR R851 1-216-041-00 RES-CHIP 470 5% 1/10W
1123 H RESISTOR R852 1-216-025-11 RES-CHIP 100 5% 1/10W
1124 H RESISTOR R853 1-216-025-11 RES-CHIP 100 5% 1/10W
1125 H SWITCH S801 1-771-734-11 SWITCH, TACTILE
1126 H SWITCH S811 1-572-347-21 SWITCH, SLIDE
1127 H SWITCH S812 1-571-760-11 SWITCH, KEYBOARD
1128 H SWITCH S813 1-571-760-11 SWITCH, KEYBOARD
1129 H THERMISTOR TH801 1-807-796-11 THERMISTOR
1130 D CAPACITOR C501 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
1131 D CAPACITOR C502 1-136-169-00 FILM 0.22UF 5.00% 50V
1132 D CAPACITOR C503 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
1133 D CAPACITOR C504 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
1134 D CAPACITOR C505 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
1135 D CAPACITOR C506 1-137-194-81 FILM 0.47UF 5.00% 50V
1136 D CAPACITOR C507 1-136-169-00 FILM 0.22UF 5.00% 50V
1137 D CAPACITOR C508 1-126-965-11 ELECT 22UF 20.00% 50V
1138 D CAPACITOR C509 1-115-522-11 FILM 1UF 5.00% 250V
1139 D CAPACITOR C510 1-117-398-11 ELECT 33UF 20.00% 250V
1140 D CAPACITOR C511 1-163-247- CERAMIC CHIP 68PF 5.00% 50V
1141 D CAPACITOR C512 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
1142 D CAPACITOR C513 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
1143 D CAPACITOR C514 1-106-375-12 MYLAR 0.022UF 99% 200V
1144 D CAPACITOR C515 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
1145 D CAPACITOR C516 1-126-934-11 ELECT 220UF 20.00% 16V
1146 D CAPACITOR C517 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
1147 D CAPACITOR C518 1-137-194-81 FILM 0.47UF 5.00% 50V
To Next Page
