- 17 -
IR MODE
1.AUTO MODE: Turn on and off IR LED automatically according to the am-
-bient darkness of photoresister. If the value of the ambient environment
(CURRENT LEVEL) is ≥ the IR ON SENS, then the LED will be turned on aut-
-omatically, vice versa. Larger CURRENT LEVEL is equivalent to darker
environment.
2.MANUAL mode: Turn on and off the IR LED manually. This can be accom-
-plished using special presets 100~103 as well. AUTO MODE is selected by
default.
IR ON SENS
The threshold for photoresister to turn on the IR LED, default is 210.
IR OFF SENS
The threshold for photoresister to turn off the IR LED, default is 185.
NOTE:
The difference between the LED ON and LED OFF values must be at least
30 to avoid problems of IR LED blinking. Only half side of IR will be on for
near view, please zoom in to enable the further view and the other side of
the IR. Use preset 103+call to manually turn on both sides together.
PATTERNS
PARK ACT
PARK TIME
SET FRAME SCAN (405 & 601 & 805)
The waiting time (or idle time) before the camera executes its PARK ACTI-
-ON (see above). The default is 25 seconds.
Set the right and left position of frame scan. Submenu as follows:
IRIS OPEN EXIT
This option is also called the watch function or the defend function of a PTZ
camera. The dome will automatically execute a corresponding preset action
after a settled idle time (25 seconds is default) if no additional commands
are sent from users.
This option has the same function as 84 + Add PRESET. To set up a pattern,
you must use direction & zoom key to add actions and Iris+ key to end the
setting. Each pattern scan can memorize no more than 31 actions.
Note: If you open the video motion & video blind function the pattern scan
will be disable.
Use preset 120+call to check the CURRENT LEVEL for 507.
