48 SUNFAR E300 SERIES
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
Slave correspond
Header
Slave addr. Slave addr.
Slave correspond
State feedback State feedback
Data type
Data addr. Data addr.
Set data Set data Set data Set data
Check sum Check sum Check sum Check sum
Ta il
Data type definition:
Function code unit F0 F1 F2 F3 F4 F5 F6 F7 F8 F9 FC FE FF FH FL FP
Data type 0 1 2 3 4 5 6 7 8 9 A B C D E F
Function code relative addr.: e.g. Data addr. of F0.8
、F1.8、F2.8、F#.8 is 8, but different data type.
Note: When slave can not finish master order, feedback setting data is 0000.
