16 SUNFAR E300 SERIES
5 PARAMETER LIST
Function Code Name Setting range
Minimum
Unit
Manu
setting
Modify
Limit
F0. 0
Freq input channel /
mode selection
0: Digital setting
1: External input signal
(0~10V / 0~20mA)
2: Serial communication
terminal (E300B series)
3: Panel potentiometer
4: External terminal selection
1 3
F0. 1 Freq digital setting 0.00 ~ upper freq 0.1 0.0
F0. 2
Operation channel
and mode selection
1st part of LED：Operation
channel selection
0：Control by keypad
1：Control by external terminal
2:Serial communication
terminal (E300B series)
2nd part of LED：Operation
mode selection
0：Two-line mode 1
1：Two-line mode 2
2：Three-line mode
3rd part of LED：Reversal
avoidance
0: Invalid 1: Valid
4th part of LED: Self-startup
when power-on
0: Prohibit 1: Allow
1 1000
F0. 3 Lower freq 0.0 Hz ~ [F0.4] 0.1 0.0
F0.4 Upper freq [F0.3] ~ 1000 Hz 0.1 50.0
F0.5 Acc time 0.1 ~ 600.0 S 0.1 10.0
F0.6 Dec time 0.1 ~ 600.0 S 0.1 10.0
F0.7
Acc / dec
characteristics
p
arameter
0: Linear acc / dec
1: S curve acc / dec
1 0
F0.8 Carrier wave freq 1.5 ~ 12.0 Khz 0.1 8.0
F0. 9 Modulate mode
0: Asynchronism
1: Synchronization
1 0 ×
F0. 10
Parameter read-in
protection
1: Only allow to modify
parameter F0.1 and this
parameter
2: Only allow to modify this
parameter
Other data: all parameter can
be allow to modify
1 0
F0. 11 Torque boost 0.0 ~ 20.0 (%) 0.1 6.0
F0. 12 Basic running freq 5.0 Hz ~ upper freq 0.1 50.0
Basic operation parameter unit
F0. 13 Max output volt 25 ~ 250V, 50 ~500V 1 220, 440
