58 SUNFAR E300 SERIES
(3) Inverter state:
Inverter state code Meaning
0x0000 Slave DC volt unprepared well
0x0001 During slave FWD running
0x0002 During slave REV running
0x0003 Slave stop
0x0004 During slave FWD jog running
0x0005 During slave REV jog running
0x0011 During FWD acc
0x0012 During REV acc
0x0013 Instantaneous stop then startup
0x0014 FWD dec
0x0015 REV dec
0x0016 Slave during DC braking state
0x0020 Slave during failure state
(4) High order of failure information code is 0, and low order corresponds to behind tab of
inverter failure code Fu., e.g. Failure information code is 0x000C, which means inverter failure
code is Fu.12.
1.2 Example
1.Start 1＃ inverter FWD running
Master claim:
Register initial addr. Register data CRC checkout
Slave addr. Function code
High order Low order High order Low order Low order High order
01 06 10 01 00 01 1D 0A
Slave correspond: Inverter FWD running returns to same data for master claim.
E300 Series Mini-type Integrated Universal Inverter Manual
