SUNFAR E300 SERIES 59
2. Set inverter running freq as 50. 0 Hz
Master claim:
Register initial addr. Register data CRC checkout
Slave addr. Function code
High order Low order High order Low order Low order High order
01 06 10 02 01 F4 2C DD
Slave correspond: inverter running for 50.0 Hz returns to same data for master claim.
3. Read inverter current running freq, output current, inverter corresponding freq 50.0 Hz
and output current 1.1A.
Master claim:
Register initial addr. Register number CRC checkout
Slave addr. Function code
High order Low order High order Low order Low order High order
01 03 D0 00 00 02 FC CB
Slave correspond:
1
st
register data 2
nd
register data CRC checkout
Slave
addr.
Function
code
Read character
number
High
order
Low
order
High
order
Low
order
Low
order
High
order
01 03 04 01 F4 00 0B FB FA
4. Start 1＃ inverter FWD running and set inverter running freq as 40 Hz.
Master claim:
Register
initial addr.
Register
number
1
st
register
data
2
nd
register
data
CRC
checkoutSlave
addr.
Function
code
High
order
Low
order
High
order
Low
order
Content
byte
number
High
order
Low
order
High
order
Low
order
Low
order
High
order
01 10 10 01 00 02 04 00 01 01 90 AF 9F
Slave correspond:
Register initial addr. Register number CRC checkout
Slave addr. Function code
High order Low order High order Low order Low order High order
01 10 10 01 00 02 14 C8
