SUNFAR E300 SERIES 17
F0. 14
Jog acc time 0.1 ~ 600.0 S 0.1 10.0
F0. 15
Jog dec time 0.1 ~ 600.0 S 0.1 10.0
F1. 0 AI input lower volt 0.0V ~ [F1.1] 0.1 0.0
F1. 1 AI input upper volt [F1.0] ~ 10.0V 0.1 10.0
F1. 2 Min setting freq 0.0 Hz ~ [F1.3] 0.1 0.0
F1. 3 Max setting freq [F1.2] ~ 1000 Hz 0.1 50.0
F1. 4
Analog output
selection
0: Output freq 1: Output
current 2: Output volt
1 0
F1. 5 AO output lower limit 0.0V ~ [F1.6] 0.1 0.0
F1. 6
AO output upper
limit
[F1.5] ~ 10.0V 0.1 10.0
F1. 7
Function selection of
input terminal 1 (0 ~
12)
1 11 ×
F1. 8
Function selection of
input terminal 2 (0 ~
12)
1 1
×
F1. 9
Function selection of
input terminal 3 (0 ~
12)
0: Control terminal idle
1: Multi-speed control 1
2: Multi-speed control 2
3: Multi-speed control 3
4: FWD jog control
5: REV jog control
6: Freq setting channel
selection 1
7: Freq setting channel
selection 2
8: Free stop control
9: Three-line mode running
control
10: DC braking control
11: REV control
12: Failure reset
1 2
×
F1. 10 Reserved
F1. 11
Output terminal OC
function selection
1 0
F1. 12
Relay output
TA/TB/TC function
selection
0: During inverter running
1: Freq reach
2: Freq level check (FDT)
3: Overload check out
4: Freq reaches upper limit
5: Freq reaches lower limit
6: During zero speed running
7: Low-volt stop
8: Inverter failure
1 8
F1.13
Freq reach check
out amplitude
0.0～ 20 Hz
0.1 5.0
F1.14 FDT (freq level) set
0.0～1000 Hz
0.1 10.0
F1.15
FDT output delay
time
0.0～ 20.0 S
0.1 2.0 ×
I/O Parameter Unit
F1.16
Overload warning
level
50～200（％）
1 110
E300 Series Mini-type Integrated Universal Inverter Manual
