3.4 Add Energy Meter
The energy meter needs to be manually added which is same as any other 3
rd
party
equipment.
To add the energy meter, click ‘Add device’ and select a device type in the pop-up
window and fill in the required information (Add device for DTSD1352/DTSU666
energy meter and device address: 254).
If it is a DTSU666 meter and not show up in the list, you may need to update the
Logger1000/EyeM4 first. Refer to the Part 5 in this document.
If the meter connected with A2 and B2
on the Logger1000, the port number on
the portal is COM2.
If the meter connected with A3 and B3
on the Logger1000, the port number on
the portal is COM3.
