2
*Helper Needed*
Tools Needed
Parts Supplied
WARNING: FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN PERSONAL INJURY! PLEASE READ
THESE INSTRUCTIONS IN ITS ENTIRETY BEFORE ATTEMPTING TO COMPLETE THIS INSTALLATION.
Figure 2 - Parts Supplied
Round Head Screw
Cable Guide Stop
with Set Screw
Flat Head Screw
Bracket
Cable Guide Bracket
Wall Mount Post Kit
Spare
CR-2430
Remote
Motorized EasyShade Assembly
PRE-INSTALLATION NOTE
Note: Prior to installing your Motorized EasyShade, please review Figure 1 (Motorized EasyShade Schemac
View) then inspect to ensure that there are no obstrucons on your wall surface, such as light xtures or
door handles, that would interfere with or block the Fabric Panel as it is extended. For proper operaon you
must ensure that the Aluminum Housing and Cable Guide Brackets are mounted on the same vercal plane
or surface.
Figure 3
or on the underside of a structure (Horizontal Surface, see Figure 4For all models, the two Mounng Brackets
should be installed no more than 10” from each end of the Aluminum Housing. For the 10’ to 12’ models, the
third Mounng Bracket should be installed at the mid point between the two End Brackets
