3) Air pressure wiring map
(1) UT-B device
[ Figure 69 ]
2.5×4×350mm
2.5×4×400mm
2.5×4×150mm
2.5×4×300mm
2.5×4×300mm
4×6×1,500mm
solenoid valve
air pressure : 0.4MPa~0.5MPa
(4Kgf/cm
2
~5Kgf/cm
2
)
IN
OUT
