14
B. Attach the safe plate to the side plate.
(You should attach it to prevent from safe accident.)
C. Connect a plug of pedal switch with control box.
[ Fig. 2 ]
[ Fig. 3 ]
Safety Plate
Face Plate
Pedal Switch
[ Caution ]
You can be hurt by the dropping device during
installation so be careful about it.
[ Fig. 4 ]
D. Install a bobbin holder on a table.
