4) Adjust the position of hammer plate
A. Back/forth movement
Loosen the bolt① and adjust the position of the hammer
plate② by moving it back and forth.
[ Fig. 24 ]
B. Spinning movement
Loosen the bolt① and adjust the position of the hammer
plate to put it at the center of the cutter.
[ Fig. 25 ]
①
①
②
