Foot Switch
1) Install and operate foot switch
A. Disassemble the hand switch attached to the bed and
remove the connector from the control box.
B. Link the foot switch connector to the control box
C. Step on the foot switch①, the clamp comes down to fix
the sewing materials.
D. When the sewing material is completely fixed, sewing
can begin by stepping on the foot switch②.
[ Fig. 36 ]
Foot switch
②
①
