it has reached the set force.
• Pre-Weld Delay - The time the weld head will wait to begin moving after receiving a
weld signal from the foot pedal or PLC
• Squeeze Time - The time the weld head will wait to start the actual weld after having
made contact with the piece. This allows the part to be settled well and give greater
consistency between welds. *The “Squeeze” option must be selected in order to use this
function.
• Hold Time - The time the weld head will continue to apply pressure after the weld has
completed before starting to move up again.
• Post Weld Delay - After the entire weld is completed, this is the amount of time before
the next weld can be initiated.
