4.3. Battery Connection
Battery connection
For safe operation and compliance, an individual DC overcurrent protector or
disconnection device is required for the connection of the battery and the inverter. Users
are recommended to utilise a suitable fuse and DC isolator (see next page). In some
applications, switching devices may not be required, but overcurrent protectors must be
used. Please refer to the typical amperage in the table below for the required fuse or circuit
breaker size.
A minimum battery cable size of 50mm diameter is recommended for the 6kW and
7.6kW inverters.
Risk of injury (Heavy Object)
Remember that this inverter is heavy so users must be careful in handling the
unit during installation.
