SINGLE PHASE HI 3.6/5kW | Installer Manual10
TECHNICAL SPECIFICATIONS
Model SYNK-3.6K-SG03LP1 SYNK-5K-SG03LP1
Battery Input Date
Battery Type Lead-acid or Li-Ion
Battery Voltage Range 48Vd.c (40Vd.c ~ 60Vd.c)
Max. Charging/Discharging Current 90Ad.c (max.) 120Ad.c (max.)
Charging Curve 3 Stages / Equalization
External Temperature Sensor Yes
Charging Strategy for Li-Ion Battery Self-adaption to BMS
PV String Input Data
Max. DC Input Power 4680W 6500W
PV Input Voltage 370V (125V~500V)
MPPT Range 150~425V
Full Load DC Voltage Range 300~425V
Start-up Voltage 125V
PV Input Current 13Ad.c + 13Ad.c
No. of MPPT Trackers 2
No. of Strings Per MPPT Tracker 1+1
AC Output Data
Rated AC Output and UPS Power 3600W 5000W
Max. AC Output Power 3960W 5500W
Max. AC Output Apparent Power 3960VA 5500VA
Peak Power(o grid) 2 times of rated power, 10s
AC Output Rated Current 16.4/15.7Aa.c 22.7/21.7Aa.c
Max. AC Current 18/17.2Aa.c 25/23.9Aa.c
Max. Continuous AC Passthrough 35A
Power Factor 0.8 leading to 0.8 lagging
Output Frequency and Voltage 50/60Hz; 220/230 (single phase)
Grid Type Single Phase
Total Harmonic Distortion (THD) <3% (of nominal power)
DC current injection <0.5% ln
Eciency
Max. Eciency 97.60%
Euro Eciency 96.50%
MPPT Eciency >99%
Protection
PV Input Lightning Protection Integrated
Anti-islanding Protection Integrated
PV String Input Reverse Polarity
Protection
Integrated
Insulation Resistor Detection Integrated
Residual Current Monitoring Unit Integrated
Output Over Current Protection Integrated
Output Shorted Protection Integrated
Surge Protection DC Type II / AC Type II
Over Voltage Category DC Type II / AC Type III

SunSynk SYNK-5K-SG03LP1 Specifications

General

Brand	SunSynk
Model	SYNK-5K-SG03LP1
Category	Inverter
Language	English
