SINGLE PHASE HI 3.6/5kW | Installer Manual68
Mode III: With Aux-Load
Mode IV: AC Couple
On-Gen+AC couple
AC cable DC cable
CT
Battery
Solar
Grid
Backup Load
On-Grid Home Load
On-Grid Inverter
Grid
Backup Load On-Grid Home Load
Battery
Solar
CT
AC cable DC cable
Aux Load
